EMI Suppression Capacitors Class X and Y type

High Voltage & High Current Capacitors in India

Advance Class X capacitors are used for Interference Suppression and across-the-line applications. Suitable for use in situations where failure of the capacitor would not lead to danger of electric shock.

Advance Class Y capacitors are used for Interference Suppression and line to ground applications. Suitable for use in situations where failure of the capacitor could lead to danger of electric shock.

Standards : IEC- 60384-14

General Specifications :

  • Non-Polar
  • Low ESR
  • Low Losses
  • High Insulation Resistance
  • Self–Healing

Applications :

  • RFI Filters
  • Power Line Frequency Applications
  • Switch Mode Power Supplies
  • Measuring Instruments

Technical Specifications :

Capacitance Range X Type – 0.1µF to 10µF
Y Type – 0.0022µF to 0.01µF
Dielectric Metallised Polypropylene Film
Rated Voltage 250/275Vac, 300Vac, 330Vac, 400Vac, 440Vac 50Hz
Tolerance ± 5%, ±10%, ± 20%
Terminals Tinned copper wires
Temperature Range -40 °C to +85 °C
Climatic Category 40/85/21
